AE系列电热式机边保温炉

AE series use electricity for heating energy,silicon carbide for heating,heat radiation directly to the surface of the aluminum liquid, high thermalefficiency, energy saving, low burning rate of liquid aluminum. No needcrucible design. The furnace is made of imported non stick aluminumcasting material.lt is controlled by temperature protection of both alumi-num liquid and atmosphere. lt can improve the temperature control accu-racy of aluminum liquid and prolong the service life of the furnace.

5.电气系统自动控制，具有故障自诊断与计算机通讯功能，可做准确的温度预设定并保存运行记录。

6.炉衬材料抗渗透能力强，使用寿命可达六年以上。

7.工业级快速接插件，可快速更换加热器，炉盖气动开闭方便出渣作业，运行稳定、安全。

1.The electric heating furnace adopts long heating element with low surfaceload, and can be replaced in the hot stove state to realize the continuous fur-nace maintenance.
2.Adopt PID temperature control, the temperature control accuracy can reach±3°℃.
3.With aluminum liquid , atmosphere and heater circuit breaker and other alarmfunctions, alarm can also automatically cut off the heater power supply, protec-tion and control system.
4.Ceramic fiber board and nano insulation material, excellent insulation effect,the average temperature rise of furnace wall is less than 25 degrees celsius.5.The electrical system is fully automatic control, it has the function of fault selfdiagnosis and computer communication.It can do accurate temperature settingand save running record.
6.Lining material has strong penetration resistance, and the service life canreach more than six years.
7.Industrial level quick connector, which can replace heater rapidly, pneumaticopening and closing of furnace lid,convenient slag discharging operation,stable, safe and reliable operation.
